CATER-M

CATER-M is a manual core cutter designed to cut cores in dust free technology. A core loading process as well as a slitting process are performed manually.

  • 1600-3000mm (63"-118.1")
    Max. parent core length
  • 1 "- 6"
    Range of core inside diameter
  • 10mm (0.4")
    Min. slit length
  • 18mm (0.6")
    Max. wall thickness

CATER-M

CATER-M - manual core cutter

CATER-M is a manual core cutter designed to slit cores in dust free technology. A core loading process as well as a slitting process are performed manually. The cut is made by a specially designed knife. The success of this model is related to satisfactory price/quality ratio. Currently there are over 700 JURMET's manual core cutters in operation all around the world.

TECHNICAL DATA

SEMI-AUTOMATIC CORE CUTTER

Max. parent core length
1600/2000/2540/3000mm (63"/78.7"/100"/118.1")
Range of core inside diameter
1"-6"
Max. wall thickness
18mm (0.6")
Min. slit length
10mm (0.4")
Electric supply
motor 400 VAC x 3 phases
Air pressure
6 bar
